The Biology of ITS sequencing

The Internal transcribed spacer (ITS) is a region in the eukaryotic genome between the genes coding for the small-subunit rRNA and the large-subunit rRNA. The ITS1 sub region in fungi is located between 18S and 5.8S rRNA genes, whereas ITS2 is between 5.8S and 28S rRNA genes. ITS regions are widely used in taxonomy due to these reasons:

• The sequence has a high degree of variation, especially between closely related species
• The size of one sub region can be easily covered with PE NGS reads
• There are universal primers available in which most fungal clades can be easily amplified

Often there are multiple copies of ITS in the same genome. However, they tend to undergo concerted evolution via unequal crossing-over events. This preserves the sequence homogeneity within a particular genome.

Most projects in the field of metagenomics have only one the two sub regions sequenced. It is not recommended to compare abundance levels between projects using different sub regions due to PCR amplification bias. Besides ITS, other marker sequences e.g. translational elongation factor 1α (TEF1α) are also used for taxonomic profiling. These markers are not covered by this webserver. However, sometimes multiple marker genes have to be sequenced for precisely taxonomic annotation up to the species level. This is also up to the clade of interest: It is usually more difficult to classify molds than yeasts using ITS region only.

Input: Uploading samples

In this tutorial we will demonstrate how to analyze the different fungal communities in fecal and environmental samples. Totaling 38 samples will be analyzed from these cohorts:

• 5 fecal samples from cancer patients (ENA study PRJEB33756)
• 20 fecal samples from healthy individuals of the HMP cohort (Nash et al., 2017)
• 13 environmental samples from a neonatal intensive care unit (NICU) (Heisel et al., 2019)

@FCBKRH9:1:2119:15517:24531 1:N:0:CAGTGCATATGC
GCATCGATGAAGAACGCAGCGAAATGCGATACGTAATGTGAATTGCAGAATTCCGTGAATCATCGAATCTTTGAACGCAC
+
CCGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGG
@FCBKRH9:1:2112:8633:25105 1:N:0:CAGTGCATATGC
GCATCGATGAAGAACGCAGCGAAATGCGATACGTAATGTGAATTGCAGAATTCCGTGAATCATCGAATCTTTGAACGCAC
+
CCGGGGGGGGFCGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGCGGGGGGG<CFGGGGGGGGGG
@FCBKRH9:1:2112:6602:7309 1:N:0:CAGTGCATATGC
GCATCGATGAAGAACGCAGCGAAATGCGATACGTAATGTGAATTGCAGAATTCCGTGAATCATCGAATCTTTGAACGCAC

muxed_S4_S5_1.fq.gz
muxed_S4_S5_2.fq.gz
S1_1.fq.gz
S1_2.fq.gz
S2_1.fq.gz
S2_2.fq.gz
S3_1.fq.gz
S3_2.fq.gz

Uploading own local samples

We will only upload the 5 fecal samples from cancer patients. Click on Input to upload new samples to your project. Here we can upload both the raw read files generated by the sequencing machine and the table containing meta data about the samples:

Upload local samples

Please wait until all files are being uploaded. A progress bar underneath the button will be provided to indicate upload status.

Adding external samples

The other two cohorts have already been uploaded to the NCBI Sequence Read Archive (SRA). This webserver is able to access this database directly. We have two options to add samples from external cohorts:

SRA Accessions

Every sequencing run stored in the SRA has a unique ID starting with either SRR, ERR or DRR followed by a number. We must enter one sample per line in the text box SRA accessions. In this example, we insert all 20 fecal samples from healthy individuals:

SRR5098710
SRR5098580
SRR5098736
SRR5098677
SRR5098500
SRR5098394
SRR5098370
SRR5098413
SRR5098489
SRR5098436
SRR5098698
SRR5098401
SRR5098363
SRR5098721
SRR5098511
SRR5098498
SRR5098398
SRR5098371
SRR5098341
SRR5098421

External projects

Many ITS projects of the SRA are already downloaded and preprocessed. We will select the project hospital metagenome Targeted loci environmental (PRJNA505509) in the drop down menu External projects by clicking at the box and typing hospital to search for the study. Please click Projects on the sidebar to browse through all available projects.

We can subset samples from external cohorts by any meta data variable as displayed at Projects. This can be archived using a filter query. We will enter the query scientific_name == 'hospital metagenome' & total_spots > 30e3 to the text box Filter query for external projects. This will only include environmental samples of the NICU project which have at least 30*10³ raw reads. Character strings must be single quoted. == is used to indicate equality. > and < can be used to filter numerical attributes. Single terms can be combined using & or | to yield the sample-wise intersection or union over these terms, respectively. Please note that both %>% and parenthesis are blocked in this filed for security reasons. We can always filter samples according to these attributes:

Attributes available in all external projects to filter samples

Attribute	Description
total_spots	Number of raw reads
total_bases	Number of raw bases
size	File size in bytes
biosample_id	NCBI accession of the biological sample starting with SAM
scientific_name	Name of taxa of the sample e.g. human gut metagenome

A click on Add external samples will add these sample to the project. The column project will be filled with the NCBI BioProject id.

Upload local samples

Start: Setting parameters and starting the pipeline

First, click on Start on the sidebar. Here we can run the pipeline with default parameters by just clicking on Start pipeline. This will take around half an hour for the example cohort to run on our servers using 5 CPU threads. Depending on the number of samples and parameters, this can take up to a couple of hours. Please create a bookmark of the page or remember the project ID to view the results later on. Results can be accessed on the sidebar above the results menu once analyzed. We also have the option to create and select own parameter sets. A complete reference about all input elements and parameters is given at Reference on the sidebar.

Logs

Once the pipeline has started, we can view the logs of the workflow engine snakemake by clicking Logs on the sidebar. This is an optional feature of this webserver and useful for debugging processes.

Result pages

Once a step is finished, a result page will be appear at the results section on the sidebar menu. All result pages follow the same structure:

• Brief description about the methods and parameters applied
• Results including summary bullet points and interactive figures
• An optional notes section with comments how to interpret the results and which errors might occurred
• A list of literature references of used tools
• Optional panels for interactive analysis and to download the results

Quality Control (QC)

Quality Control (QC) is the process of removing low quality bases from the raw reads. This is done by utilizing the Phred quality score as calculated during base calling. Furthermore, primer and adapter sequences are cut.

This is the first analysis result which will appear at the result section. The test matrix indicates whether a sample failed, raised a warning, or passed a particular QC test.

QC tests by sample

By default and in our example project, samples will be excluded from downstream analysis, if any of these tests failed:

• Adapter content is too high
• Per base N content is too high
• Per base sequence quality is too bad
• Per sequence quality scores are too low
• Minimum number of QC reads < 1000

All tests except the last one are calculated using FastQC In this table, we can see that 3 samples were excluded due to too shallow sequencing. Indeed, samples SRR5098710 and SRR5098580 do not satisfy this requirement even on raw read basis. They were included in this example project to demonstrate both the functionality of this webserver and the fact that not every sample uploaded in the SRA database is of well quality.

The effect of QC can be impressively visualized by downloading the MultiQC reports at the bottom of this page (Ewels et al., 2016). Here we can see that the adapter content and per base sequence quality has been drastically improved after QC. This is typical for ITS analyzes. If the length of the ITS sub region is smaller than the fragment length during sequencing, not only the ITS subregion itself but also the adapter of the other read mate is being sequenced. This results in high adapter content and low sequence quality due to steric hindering during the process of sequencing by synthesis.

Raw	Clean

Denoising

Denoising is the process of identifying correct biological sequences from quality controlled reads. This is done by removing potential sequencing errors.

As a sanity check, ITSx was used on the ASV sequences to see if the selected subregion ITS2 was indeed present in the raw reads:

Sanity checks

A tree of all representative sequences was generated using QIIME2, MAFFT, and FastTree (Bolyen et al., 2019; Katoh and Standley, 2013; Price et al., 2009). Here is a multiple sequence alignment of the 30 most prevalent ASVs: Please note that this tree might not reflect proper phylogeny. To do so, one need usually a much larger amplicon e.g. a whole subunit of the rRNA genes. This tree was not used anywhere else in the analysis and is only to visualize differences between all inferred representative sequences.

Phylotyping

Phylotyping is the process of taxonomic annotation of the denoised representative sequences.

59% of the AVS representative sequences were not annotated even at phylum level:

However, taking taxon abundance into account, the majority of the reads are indeed taxonomically assigned: 92% and 94% at species and phylum rank, respectively. Most representative sequences are unclassified, but very low abundant. ASV profiling searches for very subtile sequence differences up to a single base. This results into a larger number of representative sequences compared to OTU profiling.

Feature generation

Feature generation is the process of pooling denoised sequences at a given taxonomic rank. Furthermore, abundance profiles were normalized to make them comparable between differentially sequenced samples.

Features can be anything from species abundances to phylum abundances depending on the parameter set chosen. In our example, we have genus features normalized using centered log-ratio transformation (CLR). Usually there are hundreds of features remaining after feature generation. To visualize the abundance of all samples and all features, one can either generate a heatmap or reduce the dimensionality of the data set using a process called ordination. Let’s look at the results of the latter one:

Bray-Curtis	unweighted UniFrac

The webserver offers an interactive way to create ordination plots. Sample groupings, dissimilarities and ordination methods can be individually selected. In this example, Principal Coordinates Analysis (PCoA) using the dissimilarities Bray-Curtis and unweighted UniFrac was performed.

The project groups were significantly differentially abundant in both ordinations (Adonis PERMANOVA, \(p < 0.001\)). With UniFrac, however, we are able to explain 54.3% of the total variance in the first ordination axis PCo1. On the other hand, we can only explain 30.6% of it using Bray-Curtis dissimilarity. Furthermore, the sample groups tend to be more compact using UniFrac ordination.

Both dissimilarity methods aim to express the distance between two samples considering the abundances of all taxa. Bray-Curtis treats taxa as disconnected sets, whereas UniFrac takes phylogeny into account.

Let \(i\) and \(j\) be two sample groups, \(S\) the total number of species, and \(C_{ij}\) the the sum of the lesser values for only those features in common between both sample groups. Then the distances are calculated using:

\[ d_{Bray-Curtis} = 1 - \frac{2C_{ij}}{S_i + S_j} \]

\[ d_{UniFrac} = \frac{\sum \textrm{unshared branch lengths}}{\sum \textrm{all tree branch lengths}} \]

Both distances do not make a difference how much a particular feature is abundant. They only consider the pure existence. We can use weighted UniFrac to also incorporate abundance. UniFrac requires a phylogenetic tree. In this example, the tree consist of the ranks genus, family, etc. up to the kingdom. The distance of all child nodes to their parents is set to 1. This is because sequence identity from a multiple sequence alignment of denoised sequences does not correlate with phylogenetic distance in the fungal kingdom using only the ITS region.

Correlation Networks

Correlation is used to assess co-abundant features.

We used the correlation grouping disease which gave us two networks for the healthy and the diseased individuals. Here is the SparCC correlation network of the healthy individuals with default thresholds for effect size and significance (Friedman and Alm, 2012; Watts et al., 2019):

Correlation network

We can hover the cursor over an edge to get a detailed description of the correlation. Moreover, the network can be also displayed as a table by clicking on the particular tab.

For example, Malassezia is significantly negativeley correlated to Cyberlindnera (\(c_{SparCC}=-0.402, p = 0.0249\)). The p values were obtained using permutation. Other correlation methods such as BAnOCC provide confidence intervals instead of p values.

Statistics

Here, statistics refers to comparisons of feature abundance between sample groups.

Testing the same subjects multiple times requires paired testing. Subject ids can be mapped to sample ids by providing a column pair_id in the sample meta data table. We do not have to provide this pairing information in our example. We can create box plots with significance labels of any feature and sample grouping:

Two means comparison	may means comparison

Two means tests

Testing differences in the disease grouping is very simple, because disease is a binary variable (it can be either healthy or cancer)

Significant two means comparisons

Three or more means tests

The project sample grouping has three unique levels: cancer feces, healthy feces, and the environmental samples of BioProject PRJNA505509. We have to apply a two staged test here: First, Kruskal-Wallis rank sum test on normalized abundances was applied to test if there is any difference between the project groups.

Significant three or more means comparisons

Then, Dunn’s test was applied to test which groups are significantly differentially abundant. This is called post hoc testing.

Significant post hoc tests

Machine Learning (ML)

Machine Learning (ML) is the automated process of using features to build a model able to distinguish between any given classes. This model can be used to predict properties of new data sets.

Model performance

The sample property we want to classify is called target class. ML models for all categorical variables of the samples meta data table were trained. Random forests performed best in the classification of both disease and project sample target property. Feature selection improved the validation performance: All best models used recursive feature selection.

Feature importance

Multiple metrics were calculated to validate model performance:

• Sensitivity (a.k.a recall or true positive rate)
• Specificity (a.k.a true negative rate)
• Area under the receiver operating characteristic curve (AUC)

Let’s imagine a model which classifies all samples with the label cancer. This model is very sensitive: Obviously, all true cancer samples are classified correctly. But this is also for all healthy samples the case. This is why the specificity of this imagined model is 0. The performance metric to choose depends on the use case: We want a sensitive classifier for diagnosing a very severe disease for which a drug with no side effects is available. In this situation we do not care so much about false positives. However, we should focus on building a specific classifier whenever a misclassification has severe implications.

These metrics were generalized for targets with more than two levels (e.g. project): Here multiple models are trained e.g. cancer vs (healthy and environment together). Then, the performance values of the “one versus all” statistics are averaged.

Summary

You can download the full findings summary either as Excel table or HTML report at the download section of the Summary webpage.

Here, significant results from all tests are combined. Furthermore, significant features were annotated with known interactions and related literature.

Let’s see whether we have findings for Wallemia:

This is a summary of all significant group-wise comparisons and correlations. Furthermore, features were annotated with FUNGuild and two more databases: One consist of clinical isolates with suspicious fungal infections from the NRZMyk reference database. It can be accessed by clicking at Infections on the sidebar.

The other one is about known interactions to other fungi, diseases, and immune system related molecules. This database was created using manual curation of article abstracts of fungi prevalent in fecal and skin samples. It can be accessed by clicking at Interactions on the sidebar.

An overview of data protection

General

The following gives a simple overview of what happens to your personal information when you visit our website. Personal information is any data with which you could be personally identified. Detailed information on the subject of data protection can be found in our privacy policy found below.

General information and mandatory information

Data collection on our website

Tools

The general framework is based on Snakemake (Koster and Rahmann, 2012), R, Tidyverse, and Docker.

Parameters

In the input and start section, the following parameters can be set to customize the workflow:

Phred Score Format
Format of phred score used to indicate per base sequence quality of raw FASTQ read fiels.

Type: nominal
Default: phred33

Sequences to Trim (Adapters and Primers in FASTA format)
Primers and other sequences to remove from the reads. Multiple sequences are allowed. Must be provided in FASTA format. Sequence name after > is only for ducumentation purposes.

Type: string
Default: NA

Minimum read length (bp)
Minimum length of each read to pass QC. This value refers to unjoined reads. Used by trimmomatic to filter raw reads.

Type: integer
Default: 50

Include reverse complement of primer sequences
This is to indicate whether the reverse complement of sequences provided in the field ‘Sequences to Trim’ should be used as well for trimming. Highly recommended.

Type: binary
Default: TRUE

Minimim quality of trailing bases (Phred)
Minimim phred quality score of trailing bases. Used by trimmomatic for trimming trailing bases.

Type: integer
Default: 25

Minimim quality of leading bases (Phred)
Minimim phred quality score of leading bases. Used by trimmomatic for trimming leading bases.

Type: integer
Default: 25

Additional adapters
Additional adapter files to include in QC. These are the default files provided by trimmomatic.

Type: nominal
Default:

• NexteraPE-PE.fa
• TruSeq2-PE.fa
• TruSeq3-PE-2.fa

Minimum number of QC reads
Minimum number of QC reads per sample. This is to remove samples which are not deep enough sequenced. Only applied if test is set in sample exclusion criteria.

Type: integer
Default: 100

Exclude sample if any of these tests failed
Criteria to exclude samples during QC from downstream analysis. Test are provided by FastQC. Per tile test is not available for NCBI SRA samples.

Type: nominal
Default:

• fastqc_adapter_content_failed
• fastqc_per_base_n_content_failed
• fastqc_per_base_sequence_quality_failed
• fastqc_per_sequence_quality_scores_failed
• fastqc_per_sequence_length_distribution_failed
• min_qc_read_count_failed

Maximum allowed error rate
Maximum allowed error rate in QC trimming (no. of errors divided by length of matching region)

Type: integer
Default: 0.1

ITS region
ITS region to extract. Used by PIPITS. If this value is set wrong, abundance profile can not be generated.

Type: nominal
Default: NA

Denoising method
Method used for denoising. This parameter determines whether Amplicon sequencing variants (ASV) or Operational Taxonomic Units (OTU) are generated.

Type: nominal
Default: asv_dada2

PIPITS include singletons
Indication to include denoised sequence clusters with only one single sequence. Not recommended.

Type: binary
Default: FALSE

PIPITS identity threshold
Required sequence identity to cluster sequences in the same OTU. This parameters is used by VSEARCH and only applies to OTU profiling.

Type: Float [0,1]
Default: 0.97

DADA2 maximal number of undefined bases
After truncation, sequences with more than maxN Ns will be discarded. Note that dada does not allow Ns. Only used by DADA2.

Type: Float
Default: 0

DADA2 minimal base quality
After truncation, reads contain a quality score less than minQ will be discarded. Only used by DADA2.

Type: integer
Default: 0

DADA2 maximal expected errors
Default Inf (no EE filtering). After truncation, reads with higher than maxEE "expected errors" will be discarded. Expected errors are calculated from the nominal definition of the quality score: EE = sum(10^(-Q/10)). Two values for each mate are separated by a comma. Only used by DADA2.

Type: float,float
Default: 2,2

DADA2 truncate quality
Truncate reads at the first instance of a quality score less than or equal to truncQ. Only used by DADA2.

Type: integer
Default: 2

Reference database
Reference database used for taxonomic classification of denoised representative sequences.

Type: nominal
Default: Unite_8.2_dynamic

Sequence classifier
Reference database used for taxonomic classification of denoised representative sequences. The classifier will use the reference data base.

Type: nominal
Default: qiime2_blast

Minimum BLAST identity (fraction)
Minimum sequence identity required to classify denoised representative sequences. Only applied if BLAST sequence classifier is used.

Type: Float [0,1]
Default: 0.8

Taxonomic rank
Taxonomic rank at which all denoised clusters were pooled to. Used by all analysis steps as features.

Type: nominal
Default: genus

Phylogeny
Phylogenetic tree used for visualization and UniFrac based beta diversity analysis. Trees with equal edge length are allowed.

Type: nominal
Default: index_fungorum_2016

Normalization method
Normalization method used to generate features. Used in as most analysis steps as possible. SparCC and BanOCC correlation, however, rely on unnormalized counts.

Type: nominal
Default: clr

Minimum abundance to count prevalence (%)
Minimum abundance of a feature to be count as prevalent (in %). Only used for prevalence filtering.

Type: Float [0,100]
Default: 0.01

Minimum prevalence (%)
Minimum fraction of all samples a feature must be prevalent (in %) to be included in downstream analysis.

Type: Float [0,100]
Default: 5

Prevalence group
A feature is prevalent if it is prevalent in any group specified by the sample meta data column here.

Type: nominal
Default: all

Unknown strategy
Strategy to treat unassigned sequences classified as unknown.

Type: nominal
Default: infer

Inter feature correlation method
Method used to estimate correlations between pairs of features.

Type: nominal
Default: sparcc

Samples meta data
Optional file describing meta data about samples. One sample per row. Must include column sample_id. Must include columns barcode_seq and barcode_file if multiplexed files are used. CSV and XLSX (Excel) allowed.

Type: file
Default: NA

SRA Accessions (one SSR id per line)
List of SRR IDs from NCBI SRA to add. One ID per line.

Type: list of strings
Default: NA

Filter query for existing projects
Query to describe samples used to filter existing cohorts. Column names of samples meta data table must be used. Invalid characters: %, (, )

Type: string
Default: NA

Existing projects
List of projects used to add to the project. Samples selected here will be filtered by the Filter query for existing projects.

Type: list of strings
Default: NA

Local raw read files
Files to upload. File names must follow pattern {sample_id}_{mate}.{file extension} where {mate} is either 1 or 2. {sample_id} is used to map attributes in samples meta data table if provided. Allowed file extensions: fastq, fq, fq.gz, fastq.gz

Type: list of files
Default: NA

Analysis groupings
Columns of sample meta data table used to group samples in machine learning and statistics.

Type: nominal
Default: NA

Correlation grouping
Column name used to group samples to build correlation networks separately. Use all to build just one correlation network using all samples.

Type: nominal
Default: all

BanOCC chains
Number of Markov chains in BanOCC.

Type: integer
Default: 10

BanOCC total iterations
Number of total iterations for each chain (including warmup) in BanOCC.

Type: integer
Default: 10000

BanOCC warmup iterations
Number of warmup iterations for each chain in BanOCC. Must not be larger than total number of iterations.

Type: integer
Default: 5000

BanOCC alpha confidence
Fraction of the posterior density outside the credible interval.

Type: Float [0,1]
Default: 0.95

SparCC iterations and bootstraps
Number of iterations for convergence and bootstraps for p value calculation in SparCC.

Type: integer
Default: 200

Email address
Optional Email address. A HTML analysis report will be sent to this address after the pipeline has finished. You can also save this page as a bookmark to access the project.

Type: string
Default: NA

Browsers

DAnIEL was sucessfully tested with the following browers:
